Equipment Cabinet Anti‑Static Aluminum Panel

Core Advantages

• Stable anti‑static performance, surface resistivity 10⁶‑10⁹ Ω, dissipates static charge continuously, prevents ESD damage to circuit boards and chips • 5052 / 3003 aluminum substrate, moderate strength, lightweight, good corrosion resistance for long‑term indoor industrial environment • Special anti‑static coating, reduces dust attraction, keeps cabinet surface clean, easy to wipe and maintain • Excellent fabricability, supports bending, punching, cutting, riveting and welding for various cabinet sheet‑metal forming • Coating has good adhesion, won’t fall off during secondary processing • Anti‑aging coating, no fading, no chalking under long‑time equipment running temperature • Multiple color options, mostly matte gray, black, off‑white for industrial cabinet appearance • Meet ESD safety requirement for electronic workshop, data center and communication room

Production Process

Aluminum sheet cutting → Degreasing & washing → Chromium‑free passivation drying → Primer coating curing → Anti‑static functional top‑coat coating → High‑temperature baking curing → Cooling → PE protective film lamination → Dimension inspection → Surface resistance test → Flatness check → Stacking & export packaging Each batch will test surface resistivity, salt‑spray resistance and coating adhesion before delivery.

Technical Parameters

Application

IT & data industry: Server cabinet side panel, network equipment enclosure, data‑center cabinet housing Electrical industry: Electrical control cabinet, PLC control box, power distribution equipment shell Communication field: Communication equipment cabinet, signal device housing Industrial automation: Instrument housing, industrial monitor cabinet, automation equipment shell Clean‑room electronics: Electronic test‑equipment casing, anti‑static working‑table panel

Export Packaging

Panels covered with PE protective film on two sides, separated by isolation kraft paper or EPE foam to avoid scratch. Goods stacked on IPPC fumigated wooden pallets, fastened by packing straps and wrapped with moisture‑proof PE film. Shipping marks mark alloy grade, thickness, dimension, color, batch number and weight. We can provide fumigation certificate, MTC and anti‑static performance test report for overseas customer inspection and customs clearance.

FAQ

Q1: What is the surface resistance range? A: Standard grade is 10⁶‑10⁹Ω, static‑dissipative grade, fit for most electronic cabinet requirements.

Q2: Can it be bent and stamped for cabinet making? A: Yes. The anti‑static coating has good flexibility, normal bending and punching will not cause peeling.

Q3: Will anti‑static function fail after long‑time use? A: The integrated functional coating will not lose efficacy under normal indoor environment, stable for 8‑12 years service life.

Q4: What colors are mostly used for equipment cabinet? A: Matte gray and matte black are the most popular for industrial cabinets, custom RAL colors are acceptable.

Q5: What alloy is recommended? A: 5052‑H32 is preferred for cabinets, better strength and corrosion resistance; 3003‑H24 for cost‑effective projects.
