Thickness (gauge) selection is a critical technical factor when sourcing plain aluminum foil (bare aluminum foil) for flexible packaging lamination. Foil thickness directly affects moisture barrier performance, pinhole density, mechanical strength, and overall packaging cost.
Here is a practical guide to selecting the ideal micron gauge (6μm to 20μm) for your flexible packaging applications.
Double zero foils in 6.35μm and 7μm gauges are the industry standard for lightweight flexible packaging laminates (such as PET/AL/PE or Paper/AL/PE).
Key Benefit: Maximum square-meter yield per ton, providing superior cost efficiency.
Best Applications: Cigarette inner liners, candy wrappers, tea pouches, and dry food packaging bags.
Single and double zero foils between 8μm and 12μm strike an optimal balance between barrier protection and flexibility.
Key Benefit: Drastically reduced pinhole count compared to 6μm foil, offering complete light, oxygen, and aroma barriers.
Best Applications: Retort pouches, milk powder bags, coffee pouches with valves, and pharmaceutical strip packaging.
Caption: High-barrier 9-micron bare aluminum foil laminated with PE/PET films for coffee and food packaging.
Thicker gauges from 15μm to 20μm provide zero-pinhole performance and high puncture resistance.
Key Benefit: Absolute moisture barrier with high tensile strength for push-through or cold-forming lines.
Best Applications: Pharmaceutical PTP blister foil, yogurt cup lidding foil, chocolate foil wraps, and industrial tape backing.
Caption: Micrometer thickness inspection on 20μm plain aluminum foil ensuring uniform thickness and zero pinholes.
6–7 μm: Best for cost-sensitive, high-volume food and tobacco packaging.
8–12 μm: Best for premium high-barrier food pouches and retort packaging.
13–20 μm: Best for pharmaceutical PTP blister sealing, lidding, and heavy-duty barrier packaging.
We manufacture factory-direct 1235, 8011, and 8079 bare aluminum foil jumbo rolls from 6μm to 20μm with strict thickness tolerance and Grade A degreasing. Contact our packaging engineers today for technical datasheets and free test samples!
