Prepainted Aluminum Coil / Sheet for Roofing & Cladding - PE & PVDF Coating

Material: Aluminum Alloy 3003, 3105, 1050 (H14/H24)

Coating: PE (Polyester) & PVDF (Fluorocarbon)

Thickness & Width: 0.2mm - 1.5mm / 600mm - 1500mm

Color: Custom RAL Colors, Wood & Stone Grain

Application: Metal Roofing, Wall Cladding, Rain Gutters & ACP

Sales Model: B2B Wholesale / Factory Direct Export

Min Order (MOQ): 3 - 5 Tons per color/size

Standard: ASTM, EN, ISO9001 Certified

Availability:

Quantity:



Inquire Add to Basket

Product Description

Product Overview & Key Features

High-performance Prepainted Aluminum Coils & Sheets engineered for severe weather conditions and demanding architectural applications across Chile and South America. Utilizing premium PE (Polyester) and PVDF (Fluorocarbon) coating systems, our color-coated aluminum provides exceptional UV resistance, anti-corrosion protection, and long-lasting color retention for coastal and high-altitude regions.

Superior Weatherability: PVDF coating withstands harsh UV rays, salt spray, and extreme temperature variations.

Flexible Workability: High coating flexibility (T-bend: 0T–2T) ensures no cracking or peeling during roll forming, bending, or stamping.

Custom Surface Finishes: Available in high gloss, matt, metallic, wood grain, stone texture, and custom RAL color matching.

Eco-Friendly & Durable: 100% recyclable aluminum base with zero-VOC/low-emission paint treatment, offering a service life of up to 20–30 years.

Technical Specifications

Parameter / Parámetro	Specification / Detalle
Base Alloy (Aleación)	AA1050, AA1100, AA3003, AA3105, AA5052
Temper (Estado)	H14, H24, H16, H18, O
Thickness (Espesor)	0.20 mm – 1.50 mm (Tolerance: ±0.02mm)
Width (Ancho)	600 mm – 1500 mm (Standard: 1000mm, 1220mm, 1250mm)
Coating Type (Pintura)	PE (Polyester ≥ 18μm) / PVDF (Fluorocarbon ≥ 25μm)
Back Paint (Pintura Posterior)	Service coat / Epoxy primer (5μm – 8μm)
Gloss Level (Brillo)	10% – 90% (Customizable)
Standard Compliance	ASTM B209, EN 485, EN 13523, ISO 9001:2015, CE

Applications

Architectural Roofing & Cladding: Standing seam roofs, corrugated sheets, facade panels, and sandwich panel skins.

Rainwater Systems: High-durability prepainted coils for rain gutters, downspouts, and fascia covers.

Shutter & Garage Doors: Lightweight aluminum strips for roller shutters, garage doors, and sunshades.

Interior & Signage: Aluminum Composite Panel (ACP) base coil, ceiling tiles, and commercial signage.

Quality Control & Product Details

We implement strict quality inspection at every stage of production—from raw aluminum coil cleaning and chromating to double-bake coating lines and final mechanical testing.

Coating Thickness & Gloss Test: Every batch undergoes T-bend tests, cross-hatch adhesion checks, MEK rub tests, and impact resistance verification to guarantee zero paint stripping during fabrication.

Color Consistency: Computerized color-matching systems ensure precise match with target RAL colors and color uniformity between different production batches.

Seaworthy Export Packaging: Fully wrapped with waterproof plastic film, anti-rust paper, and outer steel/cardboard protection on strong eye-to-sky or eye-to-side wooden pallets.

Company Strength & Production Capacity

Advanced Production Lines: Equipped with multi-color continuous coating lines and high-speed precision slitting equipment.

Global Export Experience: Years of expertise supplying steel and aluminum coils to South America (Chile, Colombia, Peru), Middle East, and Europe.

Fast Delivery & Stocking: Large stock of primary aluminum coils (3003/1050) allowing rapid delivery within 15–20 days for custom orders.
