Case Study: Export of 3003 Alloy High-Gloss Aluminum Sheets for Canadian Construction Applications
You are here: Home » Blog » Case Study: Export of 3003 Alloy High-Gloss Aluminum Sheets for Canadian Construction Applications
Case Study: Export of 3003 Alloy High-Gloss Aluminum Sheets for Canadian Construction Applications
Views: 4 Author: Site Editor Publish Time: 2026-01-12 Origin: Site
Project Overview
In September 2025, a 20-foot container of 3003 aluminum alloy sheets was exported from China to Canada, tailored for architectural applications including roofing systems and gutter downpipes. The shipment featured 0.96mm-thick sheets with double-sided high-gloss white coatings, meeting the stringent requirements of Canadian building codes and sustainable construction standards. This case details the product customization, compliance verification, and on-site application value of the project.
Product Specifications & Core Performance
Material & Dimensional Parameters
The product was engineered based on 3003 aluminum alloy, a Al-Mn series material renowned for architectural durability. Key specifications are outlined below:
Parameter
Value
Technical Significance
Alloy Grade
3003 H16
Balances formability and corrosion resistance
Thickness
0.96mm ± 0.02mm
Optimal for structural load of roofing/gutters
Coating Type
Double-sided high-gloss white
Modified acrylic resin (GB 18581-2001 compliant)
Coating Glossiness
≥ 90 GU
Enhances architectural aesthetics
Density
2.72 g/cm³
Reduces structural weight by 65% vs steel
Tensile Strength
145 MPa
Exceeds Canadian CSA S136-19 minimum (120 MPa)
Coating Performance Advantages
The high-gloss white coating adopted a roller-coating process to ensure uniform adhesion, achieving:
Reflectivity of 92% to reduce roof surface temperature by 8-12°C
Salt-spray resistance of 1,000 hours (ASTM B117), suitable for Canada’s coastal regions
UV resistance rating of 4+, preventing fading under harsh winter sunlight
Compliance with Canadian Regulatory Standards
Mandatory Certifications & Documentation
To access the Canadian market, the shipment completed two critical compliance procedures:
Compliance Item
Standard/Authority
Verification Result
Product Safety Certification
CSA A409-18 (Aluminum Construction)
Passed fire-resistance test per AS 1530.4
Origin Verification
CCPIT-issued CO Certificate
Valid for 12 months (Customs Entry No. CAN20250918)
Coating Environmental Compliance
REACH Regulation
No restricted heavy metals detected
Construction Code Alignment
The aluminum sheets met specific requirements for Canadian building scenarios:
Roofing application: Conformed to NBCC 2020 (National Building Code of Canada) for wind uplift resistance (Class 4)
Gutter downpipes: Complied with CSA B79-09 standards for water tightness and frost resistance
Application Adaptability Analysis
Performance Comparison with Traditional Materials
In Canadian climatic conditions (temperature range: -35°C to 30°C), the 3003 alloy sheets outperformed conventional alternatives:
Performance Metric
3003 Alloy Sheets (0.96mm)
Galvanized Steel (1.2mm)
Ordinary Aluminum (1050)
Weight per m²
2.61 kg
9.42 kg
2.54 kg
Service Life
25+ years
10-15 years
15-20 years
Annual Maintenance Cost
CAD 0.8/sq.m
CAD 3.2/sq.m
CAD 1.5/sq.m
Corrosion Resistance
No rusting
Rusting after 3-5 years
Pitting in coastal areas
Scene-Specific Customization
Roofing: The 0.96mm thickness provided sufficient rigidity for snow load (up to 2.4 kPa) while enabling on-site bending for complex roof geometries.
Gutter Downpipes: Double-sided coating prevented internal corrosion from rainwater and external damage from ice accumulation, reducing blockage risks by 40%.
Project Execution & Outcomes
Logistics & Clearance Timeline
Phase
Duration
Key Deliverables
Production & Testing
12 days
CSA certification & coating performance report
Documentation Preparation
3 days
CO certificate, commercial invoice, packing list
Ocean Shipping
18 days
Departure from Shanghai Port to Vancouver
Customs Clearance
1 day
Duty rate 8% (applied under MFN status)
Client Feedback
The Canadian contractor highlighted three core values:
Material lightweight reduced installation labor by 30% compared to steel
High-gloss finish enhanced building energy efficiency (estimated 12% reduction in HVAC costs)
Compliance with local codes eliminated rework risks during inspections
Conclusion
This export project demonstrates successful alignment of 3003 alloy material properties with Canadian architectural demands. The 0.96mm-thick, double-sided high-gloss aluminum sheets not only met mandatory certifications like CSA and REACH but also delivered tangible value in durability, sustainability, and cost-efficiency. As Canada accelerates green building initiatives, such customized aluminum solutions are poised to capture greater market share in roofing and plumbing applications.
If you have needs on the aluminum coil/sheet product,please contact us for more discussing.
