ALUMINUM COMPOSITE MATERIAL SUPPLIER

What Is Aluminum Composite Material?

Aluminum Composite Material (ACM) for household appliance panels — also often called Aluminum Composite Panel (ACP) — is a three-layer sandwich-structured composite material specially developed and optimized for the exterior and interior panels of home appliances.
It is composed of two thin, high-quality aluminum alloy sheets as the surface layers, bonded firmly to a lightweight core (usually polyethylene PE, fire-retardant PE, or mineral-filled core) under high temperature and pressure. The surface is further treated with color-coated PE or PVDF finish, and protected by PE film during production and transportation.
This material is designed to meet the strict requirements of the home appliance industry, including appearance, formability, corrosion resistance, safety, and cost efficiency. It is widely used for refrigerator doors, washing machine casings, microwave ovens, air conditioners, small kitchen appliances, and other appliance panel parts.

How to choose the Aluminum Composite Material (ACM) for Household Appliance Panels?

1) Select Core Material According to Appliance Function & Safety Requirements.


For ordinary household appliances with low heat and basic fire safety demands.
Suitable: Refrigerator shells, air conditioner panels, washing machine covers, small home appliances.

-Fire-Retardant PE (FR‑PE) Core
For electrical appliances that generate heat during operation. Meets B1 fire rating.
Suitable: Microwave ovens, ovens, dishwashers, range hoods.

-Mineral‑Filled / Non‑Combustible Core
For high‑temperature built‑in appliances requiring A2 or A1 fire resistance.



2) Choose Surface Coating Based on Appearance & Service Environment.



- PE Polyester Coating
Cost-effective, good color uniformity, suitable for indoor use.
Best for: Mass‑produced standard appliances, low‑humidity environments.

- Anti‑Fingerprint (AF) Coating
Oil‑repellent, easy to clean, reduces fingerprint visibility.
Best for: Refrigerator doors, washing machine front panels, high‑end appliances.

- High‑Hardness / Anti‑Scratch Coating
Improved abrasion resistance during transportation and stamping.
Best for: Appliance tops, side panels, high‑traffic surfaces.

- Food‑Safe Water-Based Coating
Low VOC, non‑toxic, meets FDA / GB 4806.9.
Best for: Kitchen appliances, food-contact areas, inner liners.
Suitable: Built-in ovens, high-power kitchen electrical appliances.

- Mineral‑Filled / Non‑Combustible Core
For high‑temperature built‑in appliances requiring A2 or A1 fire resistance.
Suitable: Built-in ovens, high-power kitchen electrical appliances.


3) Match Aluminum Alloy & Thickness to Processing & Structural Needs.


Alloy Selection
- 1060/3003: Good formability, low cost, ideal for stamping and bending.
- 3105: Higher rigidity, better flatness for large panels.
- 5052: High strength, corrosion resistance, for load-bearing appliance shells.

Panel Thickness
-under 0.5mm: Small appliances, lightweight parts.
-upper 0.5mm: Most mainstream appliance panels (refrigerators, washers, A/C units).

4) Confirm Performance Specifications Based on Working Environment.


-Kitchen & High‑Humidity Environments
Require salt spray resistance ≥ 1000 hours, good moisture and oil resistance.

-High‑Temperature Appliances
Ensure core and coating can withstand continuous thermal cycling without deformation or discoloration.

-Indoor Long‑Term Use
Prioritize color stability, coating adhesion (≥4B), and low warpage.



5) Comply with Household & Food‑Contact Safety Standards.


Select ACM certified to:
- FDA (food contact)
- EU REACH (low heavy metals)
- GB 4806.9 (food‑grade materials for kitchen appliances)
- GB 8624 (fire performance for electrical appliances)


6) Consider Production Compatibility & Cost Efficiency.


- If using automatic stamping / bending lines: Choose high formability ACM with flexible coating.
- For mass production: Select standard thickness, stable color, low scrap rate.
- For cost control: PE core + PE coating is the most economical solution.
- For high‑end positioning: Use anti‑fingerprint, metallic, or matte textured finishes.

7) Final Summary of Typical Matching Schemes.


-Refrigerator panels:  PE core, PE coating + anti‑fingerprint
-Washing machine shells: 3003/5052 alloy, high rigidity
- Oven/microwave panels: FR‑PE or mineral core, heat‑resistant coating
-Small kitchen appliances: food‑safe compliant coating



    bg4GENERAL PARAMETERS    bg4

Aluminum Composite Material (ACM) Specifications for Household Appliance Panel Production

Parameter Category

Parameter Item

Standard Specification

Household Appliance Scenario Customization Options

Core Material Composition

Aluminum Alloy Layer (Top/Bottom)

3003/3005/3105 (food-safe & corrosion-resistant grade)

5052 (high-strength for washing machine panels); 1060 (soft for small appliance parts)

Core Material

PE (polyethylene, cost-effective for general appliances)

FR-PE (fire-retardant, for ovens/microwaves); Mineral core (A1/A2 fire rating, high-temp appliances)

Coating Type

Polyester (PE, 18–25μm, cost-effective for indoor appliances)

PVDF (25–40μm, UV-resistant for outdoor/long-life appliances); Water-based PE (low-VOC for food-contact parts)

Protective Layer

PE protective film + waterproof paper + export carton packaging

Anti-fingerprint PE film (for refrigerators/washing machines); Anti-scratch coating (for frequent-touch panels)

Physical Properties

Panel Thickness

3mm (small appliances); 4mm (standard for large appliances); 5–10mm (heavy-duty panels)

Custom thickness (3–12mm) per appliance shell size

Unit Area Weight

≤6.0 kg/m² (3mm); ≤7.5 kg/m² (4mm); ≤9.0 kg/m² (5mm)

≤5.0 kg/m² (lightweight small appliances); ≤8.0 kg/m² (large appliances)

Density

1.3–1.4 g/cm³

1.25 g/cm³ (ultra-light for portable appliances); 1.45 g/cm³ (high-rigidity panels)

Thermal Conductivity

≤0.035 W/(m·K) (PE core); ≤0.03 W/(m·K) (mineral core)

≤0.03 W/(m·K) (refrigerators, energy-saving); ≤0.02 W/(m·K) (insulated oven panels)

Mechanical Performance

Bending Performance

Minimum bending radius = 2×panel thickness (no coating cracking/peeling)

1.5×thickness (for complex curved panels, e.g., washing machine drums)

Tensile Strength

≥120 MPa (aluminum layer)

≥150 MPa (5052 alloy, high-strength panels); ≥90 MPa (1060 alloy, soft panels)

Impact Resistance

≥4 J (drop weight test, GB/T 1043.1)

≥6 J (heavy-use appliances, e.g., dishwashers)

Household Appliance-Specific Performance

High-Temperature Resistance

≤120°C (PE core); ≤200°C (mineral core)

≤150°C (FR-PE core, microwave ovens); ≤250°C (mineral core, built-in ovens)

Corrosion Resistance

Salt spray resistance ≥1000h (GB/T 10125)

≥1500h (kitchen appliances, high humidity/acidic environment)

Food-Contact Safety

Complies with FDA 21 CFR, EU REACH, GB 4806.9

GB 4806.9 (strict food-contact grade for kitchen appliances)

Fire Rating

B1 (FR-PE core, GB 8624); A1/A2 (mineral core)

A2 (built-in ovens/microwaves); B1 (general household appliances)

Processing Adaptability

Processing Compatibility

CNC cutting, laser cutting, shearing, stamping, bending

Roll forming (for refrigerator door panels); Embossing (for textured surfaces)

Processing Waste Rate

≤3% (precision cutting)

≤2% (mass production optimization)

Forming Precision

±0.1mm (size tolerance)

±0.05mm (high-precision small appliances)

Quality & Compliance

Coating Adhesion

≥4B (cross-cut test, GB/T 9286-1998)

≥5B (high-adhesion coating for frequent-touch panels)

Color Consistency

ΔE ≤1.0 (batch-to-batch, Pantone/RAL matching)

ΔE ≤0.5 (brand-exclusive color panels)

Defect Rate

≤0.3% (finished product inspection)

≤0.1% (high-grade appliance panels)

Cost Optimization

Raw Material Cost Reduction

25–35% vs. solid aluminum sheets (less aluminum usage)

20–30% vs. stainless steel panels

Logistics Cost Reduction

30–50% vs. solid aluminum (lightweight)

20–40% vs. steel panels (lower density)

Tooling Life Extension

25–30% longer vs. solid aluminum (lower tooling wear)

30–35% vs. steel panels (softer material)
