Aluminum Alloy 8011
Dingang
| Aluminum Alloy: | |
|---|---|
| Aluminum Foil Thickness: | |
| Color Options::: | |
| ID: | |
| Temper: | |
| Availability: | |
| Quantity: | |
AA8011-O printed aluminum foil is a soft, highly formable packaging material for confectionery, specialty food, beverage mixes, cosmetics, promotional products and other consumer packaging requiring metallic appearance, custom graphics and controlled converting performance.
The current product range covers approximately 6μm to 25μm foil thickness in O temper with a 76mm core. Multi-color rotogravure printing can be developed for logos, product information, PANTONE-based brand colors, metallic effects, fine patterns, barcodes and other consumer-facing graphics.
The aluminum substrate provides a naturally metallic visual base that can be combined with transparent, opaque and specialty inks to create different levels of metallic brilliance. Final appearance should be approved using an actual printed foil sample because reflective aluminum can change the perceived color compared with paper or white plastic film.
For food, nutraceutical or other regulated packaging, the complete construction must be evaluated, including foil, printing ink, primer, protective lacquer, adhesive, laminate and sealing layer where applicable.
Aluminum foil provides a reflective metallic substrate that can create visual effects that are difficult to reproduce on ordinary paper or opaque plastic. Transparent inks can allow metallic reflection to remain visible, while opaque white and solid colors can be used where a conventional non-metallic printed appearance is preferred.
Rotogravure printing supports detailed artwork and repeat production, but brand color should be controlled against an approved printed sample rather than assuming identical appearance across aluminum, paper and plastic substrates.
Thin aluminum foil provides a distinctive metallic hand feel and useful fold retention that can support premium confectionery, specialty food and promotional packaging.
Required compliance documentation should be identified according to the actual product, packaging structure, destination market and conditions of use. The foil alloy alone does not establish compliance for printing inks, adhesives, lacquers or polymer layers.
Continuous intact aluminum foil provides excellent opacity and very strong barrier performance. Finished-package protection also depends on foil gauge, pinholes, folds, flex cracking, seals, puncture resistance and any additional laminate layers.
Technical Property | Current Specification | Purchasing Guidance |
|---|---|---|
Product | Printed Aluminum Foil | For modern consumer, food and branded retail packaging |
Alloy | AA8011 | 8xxx-series packaging foil alloy suitable for thin-gauge converting applications |
Temper | O Temper | Fully soft condition selected for wrapping, folding and flexible converting |
Thickness | 6–25 μm | Final gauge should match wrapping, barrier, printing and machine requirements |
Core ID | 76 mm | Confirm reel OD, reel weight and core compatibility with downstream equipment |
Gauge Tolerance | Current Target: ±3% | Final contractual tolerance should be confirmed for the exact thickness |
Printing Method | Rotogravure | Suitable for repeat graphics and high-volume branded packaging |
Printing Colors | Up to 10 Colors According to Current Program | Actual number of stations depends on artwork, white ink, varnish and metallic effects |
Color Reference | PANTONE / Approved Printed Proof / Customer Standard | Physical proof recommended for brand-critical metallic graphics |
Surface Energy | Current Target: 38+ dynes/cm | Used as a wetting indicator; final adhesion must be verified with the actual ink system |
Surface Configuration | Bright / Matte Orientation According to Foil and Printing Requirement | Specify which side is printed, coated, laminated or product-facing |
Primer | Application-Specific | Primer should match foil surface, ink chemistry and end-use conditions |
Protective Lacquer | Optional / Application-Specific | Can support rub resistance, gloss control and print protection |
Embossing | Available Subject to Pattern and Gauge | Embossing should be coordinated with print registration and foil thickness |
Lamination | Paper / Polymer Film / Custom Structure Where Applicable | Adhesive and laminate structure should match sealing, barrier and mechanical requirements |
Supply Form | Roll / Slit Roll / Converted Sheet Where Applicable | Specify width, OD, weight, winding direction and splice requirements |
Food-Contact Documentation | Application- and Market-Specific | Compliance review should include inks, lacquers, adhesives and other relevant layers |
The specifications above should be converted into a final purchase specification for each project. Foil gauge, printing, surface energy, barrier, reel configuration and regulatory documentation are separate requirements and should be verified independently.
Send Your Printed Foil Specification
O temper is fully soft annealed and provides the flexibility required for wrapping, folding, laminating and other thin-foil converting operations.
Soft aluminum foil can retain folds with relatively low spring-back compared with many polymer films. This can be useful in confectionery wrapping and other packages where the material needs to stay closely formed around the product.
Dead-fold performance should still be verified using the actual foil gauge, coating, ink, laminate and product geometry.
Aluminum is naturally opaque and provides a metallic visual surface. These characteristics can support both product protection and distinctive consumer-facing design.
Foil Gauge Direction | Typical Benefit | Important Consideration |
|---|---|---|
6–9 μm | Very low material weight for laminate structures | Pinhole, flex-crack and puncture control become especially important |
10–15 μm | Useful balance for many wrapping and flexible-packaging structures | Machine handling, dead-fold and barrier requirements should be matched to the application |
16–25 μm | Greater stiffness, handling strength and pronounced embossing capability | Higher material weight and different forming behavior |
Surface-energy control is important because inks and coatings must wet the aluminum surface before they can form a reliable printed film.
The current product program lists a 38+ dynes/cm surface-energy target. This value is useful as a process-control indicator, but it should not be interpreted as a guarantee of ink adhesion or print durability.
Dyne testing provides an indication of surface wetting. The appropriate surface-energy level depends on the surface tension and chemistry of the actual ink, lacquer or adhesive.
Rolling oil, dust and contamination can reduce printing or laminating performance even if the measured dyne value appears acceptable.
Ink adhesion should be checked on the cured printed foil using an agreed tape, rub, scratch or other application-specific test.
Rotogravure printing is suitable for repeat consumer-packaging graphics, fine patterns, solid colors and multiple printing stations. The current program supports up to 10 colors according to artwork and press configuration.
PANTONE references can be used for ink formulation, but the metallic foil background influences perceived color. Brand-critical designs should be approved using an actual printed foil proof.
Transparent and translucent inks can preserve some of the aluminum reflection and create metallic color effects without adding a separate metallic ink layer.
Opaque white can be printed beneath selected artwork where the brand requires a color appearance less influenced by the reflective aluminum substrate.
Minimum text size, line width, barcode contrast and print registration should be reviewed during artwork preparation rather than assumed from the total number of available colors.
Printed foil should not be described as providing universally perfect color reproduction. Color appearance depends on ink formulation, foil surface, white underprint, lacquer, printing conditions, lighting and viewing angle.
A signed or approved production proof provides a practical reference for repeat orders and future production batches.
Where required, buyers can specify measurement conditions and an acceptable ΔE tolerance for selected solid colors.
Metallic graphics should also be evaluated visually under agreed lighting because reflection can cause appearance changes that a single color measurement does not fully describe.
Printed foil should be ordered according to the downstream packaging or laminating machine rather than by thickness and width alone.
Required roll width
Core ID
Maximum reel outside diameter
Maximum reel weight
Printed side orientation
Unwind direction
Inside- or outside-wound print
Print repeat length
Splice quantity and identification
Slit-width tolerance
Continuous intact aluminum foil provides complete opacity to visible light and can provide extremely low transmission through the solid metal layer.
This does not mean every printed foil package is automatically airtight, waterproof or suitable for a fixed shelf-life period.
Pinhole control becomes increasingly important as foil thickness decreases. Barrier-critical projects should define an inspection method and allowable pinhole criteria.
Repeated folding and flexing can damage very thin foil. Packages exposed to substantial flexing should be tested as a complete laminate or wrapper.
Finished-package protection depends on closure and sealing design. Bare aluminum foil does not provide a conventional heat-seal surface without a suitable lacquer, adhesive or polymer sealant layer.
Printed foil can be incorporated into laminated structures where polymer film, paper or a heat-seal coating provides additional mechanical, sealing or converting functions.
PET, PE, PP, CPP, PA and other films can be considered in suitable structures, but the exact laminate should be designed around seal temperature, puncture resistance, barrier requirement and product compatibility.
Paper can provide stiffness, print support or tactile character in foil-paper structures. Adhesive compatibility and curl should be evaluated during converting.
Where foil must seal directly to a cup, film, tray or paper substrate, the heat-seal lacquer must be selected for the exact mating material and sealing process.
AA8011-O alloy and a metallic aluminum barrier do not automatically make a complete printed package compliant for every food or market.
Food-contact materials placed on the EU market should be evaluated under the applicable framework requirements, including Regulation (EC) No 1935/2004 and relevant good manufacturing practice requirements.
Printing inks placed on the non-food-contact side must be formulated and processed so that substances do not transfer to the food-contact side through the substrate or by set-off at levels that would make the finished material non-compliant.
Conventional printed surfaces should not directly contact food unless a specific compliant construction has been designed and validated.
EU Regulation 10/2011 applies specifically to plastic food-contact materials. It can be relevant where a printed foil structure includes plastic films or polymer layers, but it should not be described as a universal certification for bare or printed aluminum foil by itself.
U.S. food-contact suitability depends on the substances used, intended food-contact application and conditions of use. Inks, adhesives, coatings and other packaging components should be reviewed as part of the actual finished structure.
Projects requiring SFDA, SASO or other GCC documentation should identify the destination country, product type, intended contact conditions and required supporting documents before production.
When printed foil is wound into a reel, the printed surface can contact the opposite side of the next layer. This creates a potential set-off pathway for substances from ink or coating to reach the product-contact side.
Ink formulation, curing, reel storage and winding conditions should therefore be controlled for food-contact packaging.
Printed AA8011-O foil is suitable for selected chocolate, candy and confectionery wrapping where metallic appearance, folding performance and custom graphics are required.
Confectionery projects should specify whether the foil contacts the food directly, whether paper backing is used, the expected grease exposure, wrapping-machine speed and the required finished wrapper dimensions.
Printed aluminum foil can be used as a barrier layer or wrapper in suitable specialty-food sachets and laminate structures.
The foil layer contributes light and barrier performance, while sealing, puncture strength and package integrity normally depend on the full laminate and sealant structure.
Beverage powders, drink mixes and other moisture-sensitive dry products can use aluminum-foil laminates when high barrier and printed presentation are required.
Moisture protection should be validated using the complete package, seal and storage conditions rather than assigned from the foil layer alone.
Printed foil can be incorporated into suitable sachets, wraps and laminated packs for selected powdered supplements and consumer health products.
Product registration, pharmaceutical requirements, nutritional labeling and regulatory approval are separate from the foil substrate specification and must be addressed according to the destination market and finished package.
Metallic printed foil can be used for decorative liners, sachet laminates and premium consumer packaging for cosmetics and personal-care products.
Direct contact with fragrance oils, alcohol-rich formulas or active cosmetic ingredients requires chemical-compatibility evaluation of the complete package structure.
Consumer packaging can incorporate selected brand-protection features such as micro-text, fine-line graphics, serialized codes, QR codes and specialty inks where compatible printing capability is available.
Holographic patterns, optically variable devices and advanced authentication technologies can require dedicated films, embossing, transfer processes or separate conversion and should be specified independently.
Metallic substrates can create scanner reflections that reduce barcode or QR-code contrast if the design is not optimized.
Codes should therefore be verified using the actual printed foil, intended scanner and final package geometry before bulk production.
Embossing can add logos, repeating patterns, texture or tactile differentiation to printed foil.
The embossing process should be coordinated with artwork and registration because deep deformation can alter printed graphics or affect thin-foil integrity.
AA8011-O should be verified where alloy and temper are contractual requirements.
Gauge should be measured against the agreed nominal thickness and tolerance because variation influences roll length, wrapping behavior and barrier performance.
Slit width, edge quality and roll alignment should match downstream printing, laminating or packaging machinery.
Dyne testing can be used to monitor print-side wettability before printing, coating or lamination.
Oil residue, particles and contamination should be controlled because they can affect print adhesion and laminate bonding.
Registration tolerance should be controlled for multi-color graphics, small type, fine patterns, barcodes and overlapping design elements.
Brand-critical programs can define a printed master sample and agreed instrumental color tolerance.
Tape, rub or another agreed adhesion test should be completed after printing and curing.
Packages exposed to high-speed machinery, distribution and retail handling can include a defined rub or scuff-resistance requirement.
Protective lacquer should be evaluated for adhesion, curing, rub resistance and any required heat or product-contact conditions.
Barrier-critical thin foil can include maximum pinhole size, count or inspection criteria in the purchase specification.
Finished reels should be checked for wrinkles, telescoping, edge damage, loose winding and other conditions that can interfere with high-speed converting.
Barcode and QR-code designs should be verified on the finished metallic package under representative scanning conditions.
Where regulated consumer or food packaging requires migration testing or declarations, documentation should correspond to the exact supplied ink, lacquer, adhesive, laminate and conditions of use.
For accurate specification review and pricing, please provide:
Final consumer packaging application
Required foil thickness
Required roll width
Core ID
Maximum reel OD and reel weight
Artwork file
Number of printing colors
PANTONE or physical color reference
Transparent or opaque metallic effects
White underprint requirement
Print repeat length
Unwind and printing direction
Primer requirement
Protective lacquer requirement
Embossing requirement
Paper or polymer lamination structure
Heat-seal requirement if applicable
Barcode, QR or security-printing requirement
Pinhole requirement where barrier-critical
Food-contact requirement if applicable
Destination-market documentation
Order quantity
Destination port or delivery location
Get a Custom Printed Foil Proposal
It is printed aluminum foil designed to combine metallic surface effects with custom graphics for branded consumer packaging such as confectionery, specialty foods, beverage mixes and selected cosmetic products.
The current product is based on AA8011 in O temper, providing a soft foil condition suitable for wrapping and flexible converting.
The current product range is approximately 6μm to 25μm.
The current specification lists a 76mm core. Reel OD and weight should also be provided when packaging-machine limits apply.
The current rotogravure program supports up to 10 colors according to artwork and press configuration.
Yes. PANTONE can be used as a color-development reference, but the metallic substrate affects final appearance. An actual printed foil proof is recommended for final approval.
No. It indicates suitable surface wetting potential, but final adhesion depends on cleanliness, primer, ink chemistry, curing and protective coating.
Printed durability depends on ink, curing, lacquer and handling conditions. Rub, adhesion and other relevant tests should be specified where print durability is important.
Yes. Transparent or translucent ink can allow the reflective aluminum beneath it to create metallic color effects.
Yes. Opaque white or other ink layers can reduce the visual influence of the metallic substrate where the design requires conventional solid-color appearance.
Dead-fold describes the ability of soft foil to retain a fold with relatively little spring-back. Actual performance depends on foil gauge and the complete converted structure.
Yes, where the selected foil gauge, print design and embossing pattern are compatible. A production trial is recommended.
Yes. Suitable paper and polymer laminates can be developed when adhesive, curing, sealing and barrier requirements are matched to the intended package.
Intact continuous foil provides excellent barrier performance, but the finished package can be affected by pinholes, flex cracks, folds, seals, punctures and other laminate components.
No fixed shelf-life period should be assigned to foil alone. Shelf life depends on the product, package structure, sealing process, filling conditions and storage environment.
No blanket claim should be made. Food-contact suitability depends on all substances in the finished package and their intended conditions of use.
No. EU 10/2011 specifically concerns plastic food-contact materials and can be relevant when plastic layers are part of the packaging structure.
Conventional food-packaging print is normally kept on the non-food-contact side. Direct contact requires a specifically designed and validated compliant system.
Set-off is transfer from a printed surface to the opposite side when printed material is stacked or wound into a reel. It is an important control point for food-contact packaging.
It can be incorporated into suitable consumer health-product packaging, but the finished package and product must meet the regulatory requirements of the destination market.
Yes, for compatible decorative or laminated cosmetic packaging. Direct contact with active formulations requires separate compatibility review.
Micro-text, fine graphics, QR codes, serialization and compatible specialty inks can be discussed. More advanced holographic or optically variable features require separate process confirmation.
Please provide foil thickness, width, artwork, number of colors, color references, print repeat, reel dimensions, winding direction, lacquer or laminate structure, barrier requirements, food-contact requirements, quantity and destination.
Yes. Metallic print appearance, registration, color and gloss are sensitive to actual production conditions, so printed proofs or representative production samples should be approved before commercial production.
