Aluminum Alloy 8011
Dingang
| Aluminum Alloy: | |
|---|---|
| Aluminum Foil Thickness: | |
| Color Options::: | |
| ID: | |
| Temper: | |
| Availability: | |
| Quantity: | |
Tear-resistant lacquered aluminum foil is designed for high-speed confectionery wrapping applications where stable unwinding, controlled surface friction, consistent gauge, clean slit edges and reliable folding or twisting performance are important.
The current product uses AA8011 aluminum in soft O temper with a published thickness range of 0.009mm to 0.020mm and a thickness tolerance of ±3%. Its soft temper supports forming and dead-fold behavior, while controlled mechanical properties help the foil accommodate rapid acceleration, folding and twisting forces on compatible candy wrapping equipment.
High-slip decorative lacquer and application-specific heat-seal or cold-seal coatings can be developed according to the wrapping format. Machine speed, tear performance, coefficient of friction, sealability and food-contact construction should be confirmed against the actual candy, wrapper geometry and packaging line.
Request a High-Speed Candy Foil Quotation
Technical Property | Published / Available Specification | High-Speed Line Consideration |
|---|---|---|
Product Type | Lacquered aluminum foil for high-speed confectionery wrapping | For compatible twist, fold, flow-wrap and confectionery converting processes |
Primary Alloy | AA8011 | Confirm alloy and mechanical properties in the purchase specification |
Temper | O temper / Soft annealed | Supports formability, folding and compatible twist-wrapping processes |
Thickness | 0.009–0.020mm / 9–20μm | Select according to candy geometry, machine stress, barrier and wrapping format |
Thickness Tolerance | ±3% current published reference | Gauge uniformity contributes to stable web tension and forming performance |
Tensile Strength | ≥75 MPa current published reference | Confirm test method, specimen direction and conditioning where contract-critical |
Elongation | To be specified according to application | Important together with tensile strength for absorbing short-duration packaging loads |
Kinetic Coefficient of Friction | <0.30 current published reference | Specify test method, tested surface and mating material before contractual use |
Outer Surface | High-slip decorative lacquer available | Optimize for machine friction, scuff resistance and visual appearance |
Seal Coating | Heat-seal or cold-seal construction available according to application | Specify substrate, seal pattern, temperature or cold-seal conditions and seal-strength target |
Food-Contact Documentation | SFDA / SASO / FDA / EU 10/2011 references currently published | Request current documentation for the exact foil, lacquer, seal coating and intended market |
Published tensile strength, thickness tolerance and coefficient-of-friction values should be linked to an agreed test method when used as contractual acceptance criteria.
Request Foil Samples & Machine Trial Material
Tear resistance in high-speed candy foil is influenced by several properties rather than by tensile strength alone.
Important factors include foil thickness, alloy, temper, elongation, rolling quality, slit-edge condition, surface defects, coating friction, winding tension and the dynamic forces generated by the packaging machine.
Tensile strength describes the stress the foil can withstand during a controlled tensile test. The current published reference for this product is ≥75 MPa.
A tensile result alone does not predict every web break because packaging-line failures can start from local defects or edge notches at stresses below the uniform tensile strength of the foil.
Elongation describes how much the material can deform before fracture. For high-speed wrapping, the required balance between tensile strength and elongation should match the sudden acceleration, folding and twisting imposed by the machine.
Small edge defects can act as stress concentrators. Once a tear starts at a damaged edge, it can propagate rapidly across thin unsupported foil.
Precision slitting is particularly important for thin foil used on automatic confectionery lines. Finished width, edge condition and winding quality should be controlled for the intended machine.
Slit edges should be free from unacceptable burrs, edge folds, cracks and mechanical damage that could initiate tearing during unwinding or wrapping.
Finished roll width should match the forming, folding or twisting tooling. Excessive width variation can affect web tracking and the position of folds or seals.
Consistent roll-edge alignment helps the web enter high-speed guides and wrapping stations without unnecessary lateral correction.
Surface friction can strongly affect foil movement through guides, folding plates, collars and other machine-contact surfaces.
The current product information lists a kinetic coefficient of friction below 0.30. Where this value is specified contractually, the test surface, mating material, conditioning and test method should also be identified.
Excessive friction can increase drag and web tension, contributing to wrinkles, tracking instability or tearing when the line accelerates.
Extremely low friction can also create handling problems in equipment that depends on controlled traction for feeding, gripping or registration.
The best friction level depends on the wrapper surface, machine-contact materials, wrapping format and line design. Production trials are recommended for new high-speed applications.
Uniform winding tension helps reduce wrinkles, telescoping, loose edges and sudden tension changes during rapid unwinding.
Core ID should match the packaging-machine unwind shaft or chuck. The required core dimension should be specified at quotation.
Maximum OD should match machine clearance and unwind capacity. Large rolls can reduce changeovers but also increase roll mass and inertia.
The decorative lacquer, food-contact side and seal-coated side should be oriented correctly for the intended machine. Winding direction should therefore be defined in the purchase specification.
For continuous high-output production, maximum splice quantity, splice construction and identification can be agreed in advance.
Maximum packaging speed cannot be determined from foil tensile strength alone.
Actual line speed can depend on:
Packaging-machine manufacturer and model
Single-twist, double-twist, fold-wrap or flow-wrap format
Candy dimensions and shape
Foil thickness
Web width
Tensile and elongation behavior
Coefficient of friction
Slit-edge condition
Roll tension and inertia
Heat-seal or cold-seal system
Machine acceleration and deceleration profile
For critical high-output lines, production-representative machine trials should be used to establish the acceptable operating window before full commercial supply.
Twist wrapping places concentrated torsional stress around the ends or neck of the wrapper. Suitable foil should balance softness, strength, twist retention and resistance to tear initiation.
Double-twist formats are commonly used for individual hard candies, sweets and selected chocolate products. The foil should be tested for twist retention and neck-tear resistance at the actual twisting force and machine speed.
Single-twist formats can impose asymmetric stress on the wrapper. Material trials should confirm that the foil forms cleanly and remains stable without excessive tearing or unwanted spring-back.
Dead-fold and twist retention are related but not identical performance characteristics.
Dead-fold describes the ability of aluminum foil to retain an imposed fold with relatively little spring-back. This is useful for fold wrapping and shaped confectionery.
Twist retention describes how well the wrapper maintains a twisted closure after mechanical twisting. It depends on foil gauge, temper, coating construction and twist geometry.
Heat-seal lacquer can be applied where the candy wrapper requires thermal bonding to itself or another compatible packaging surface.
The required seal initiation temperature depends on lacquer chemistry, coating weight, mating surface and machine conditions.
Heat-seal strength should be defined with the relevant sealing temperature, pressure, dwell time, specimen width and test method.
High-speed machines benefit from a practical sealing window that tolerates normal process variation while maintaining acceptable seal performance.
Cold-seal systems can be considered for heat-sensitive confectionery or high-speed wrapping formats where sealing without substantial heat input is required.
Cold-seal coating is commonly applied in a defined pattern rather than over the complete web. The coating registration should match the final wrapper seal area.
Roll construction should be designed so the cold-seal layer does not create unacceptable blocking or transfer during winding, storage and unwinding.
The required bond strength should be tested with the actual coating pattern, pressure and mating surface used on the packaging line.
Lacquered aluminum foil can be evaluated for compatible flow-wrap constructions where sealing and machine handling requirements have been properly defined.
Unsupported aluminum foil should not automatically be assumed to behave like a polymer flow-wrap film. The sealing system, fold pattern, web tension and machine configuration should be confirmed through line trials.
Soft 8011-O aluminum foil can be evaluated for high-speed single- or double-twist wrapping of hard candies and compatible lozenges where the selected gauge, coating and machine setup provide sufficient twist and tear performance.
Chewy caramel, toffee and nougat products can create different release, grease and adhesion requirements from hard-boiled candy.
The food-contact coating should therefore be evaluated with the actual formulation rather than assuming that every lacquer provides universal non-stick performance.
For mini-pouches or sachets containing dragees, lentils or small candy pieces, a converted laminate or appropriately seal-coated aluminum construction can be developed according to the form-fill-seal process.
Pouch or sachet applications should be distinguished from unsupported twist-wrap foil because the required mechanical and sealing behavior can be different.
Food-contact suitability should be assessed for the complete wrapping construction rather than from the AA8011-O alloy alone.
Relevant components can include:
Aluminum foil substrate
Food-contact lacquer
Decorative lacquer
Heat-seal coating
Cold-seal coating
Printing inks
Primers or overprint coatings
For EU food-contact use, the complete material should meet applicable general food-contact and Good Manufacturing Practice requirements. Where plastic or polymer layers are present, the relevant material-specific requirements should also be reviewed.
For U.S. applications, the regulatory basis of applicable coatings, adhesives, colorants and other food-contact substances should match the intended confectionery product and conditions of use.
The current product information references SFDA and SASO. Customers supplying the Saudi market should identify the exact documents required for the supplied wrapper construction and obtain current supporting documentation.
The term “zero migration” should not replace analytical qualification. Migration behavior depends on the coating formulation, candy composition, contact conditions and applicable test requirements.
High-sugar and fat-containing confectionery can interact differently with coatings. Product compatibility should therefore reflect the actual candy formulation and storage conditions.
Where confectionery is sensitive to foreign odors or flavors, the wrapping construction can be evaluated using an appropriate organoleptic or sensory test.
Inspection Item | What to Confirm |
|---|---|
Alloy and Temper | AA8011-O according to purchase specification |
Thickness | Required 9–20μm gauge and ±3% published tolerance where agreed |
Tensile Strength | ≥75 MPa published reference with agreed test method |
Elongation | Application-specific target where required |
Kinetic CoF | <0.30 published reference with defined test surfaces and method |
Slit Edge | Burrs, cracks, edge folds, tears and width tolerance |
Roll Flatness | Wrinkles, gauge bands and web flatness |
Winding Quality | Roll hardness, telescoping, edge alignment and unwind stability |
Lacquer Adhesion | Required adhesion or rub test |
Scuff Resistance | Representative machine-contact and distribution abrasion test where required |
Heat-Seal Strength | Seal temperature, pressure, dwell time and test method |
Cold-Seal Performance | Pattern registration, blocking, release and bond strength where applicable |
Food-Contact Surface | Applicable material construction and supporting documentation |
Machine Trial | Web-break frequency, tracking, wrapping quality and maximum stable operating window |
Thin lacquered foil should be protected from edge impact, moisture, dust, abrasion and roll deformation during transportation and storage.
Roll ends and slit edges require particular protection because edge damage can create tear-initiation points during high-speed unwinding.
Storage temperature and humidity should follow the recommendations applicable to the foil coating and any heat-seal or cold-seal layer.
For an accurate high-speed candy foil quotation, please provide as much of the following information as possible:
Hard candy, caramel, toffee, nougat, lozenge, chocolate or other confectionery product
Single-twist, double-twist, fold-wrap, flow-wrap or sachet format
Required AA8011-O specification
Foil thickness between 9μm and 20μm
Thickness tolerance
Required tensile strength
Required elongation
Required coefficient of friction
CoF test method and mating surface
Finished roll width
Width tolerance
Core inner diameter
Maximum roll outside diameter
Preferred or maximum roll weight
Winding direction
Maximum permitted splices
Decorative lacquer requirement
Heat-seal or cold-seal requirement
Heat-seal substrate and seal-strength target
Cold-seal pattern and bond-strength target
Lacquer rub or scuff-resistance requirement
Color and printing requirement
Food-contact side
Migration or organoleptic requirements
Packaging-machine manufacturer and model
Current production speed
Target production speed
Current web-break or machine-running issue, if applicable
Candy dimensions and weight
Required food-contact documentation
Order quantity
Destination country or delivery port
Send Your Candy Wrapping Specifications
It is thin aluminum wrapping foil engineered for compatible confectionery lines where tensile behavior, elongation, slit-edge quality, surface friction and winding stability are controlled to reduce the risk of machine-induced tearing.
The current product specification uses AA8011 in soft O temper.
The current published range is 0.009mm to 0.020mm, equivalent to 9μm to 20μm.
The current product specification lists ±3%. The measurement and sampling method should be agreed where this tolerance is contractual.
The current product information lists tensile strength of at least 75 MPa. Test method and specimen direction should be confirmed for contractual use.
No. Web tearing can also be caused by edge defects, excessive tension, poor alignment, wrinkles, machine acceleration, incorrect friction or localized damage.
Elongation indicates how much deformation the foil can accommodate before fracture and should be considered together with tensile strength for high-speed wrapping.
The current product information lists kinetic CoF below 0.30. The tested surface, mating material, conditioning and test method should be specified when comparing results.
No. Excessive friction can increase drag, while excessively low friction can reduce controlled feeding or gripping. The required range depends on the specific packaging machine.
Small cracks, burrs or folds along the web edge can act as tear-initiation points when the foil is under dynamic tension.
Maximum stable speed depends on the machine, candy geometry, wrapping format, foil width, gauge, friction, sealing process and web tension. A production trial is required before assigning a specific speed.
Yes, it can be evaluated for compatible double-twist candy wrapping. Twist retention and neck-tear resistance should be confirmed on the actual machine.
Yes, compatible single-twist applications can be evaluated according to foil gauge, twisting geometry and machine settings.
No. Dead-fold refers to retention of a fold, while twist retention refers to the ability to maintain a twisted closure. Both can be important but should be evaluated separately.
Heat-seal constructions can be discussed according to the required mating surface, seal temperature, pressure, dwell time and seal-strength target.
Cold-seal coating can be evaluated for compatible confectionery applications. Coating pattern, registration, blocking and bond strength should be defined for the intended line.
It can be evaluated for compatible products, but the food-contact coating should be tested against the actual caramel, toffee or nougat formulation for release and compatibility.
No. Package tightness depends on the wrapper format, sealing system, folds, coating, machine setup and finished-package integrity.
Migration should be evaluated under the applicable food-contact requirements for the exact coating, confectionery type and contact conditions rather than described as universally zero.
Custom decorative colors and printing can be discussed according to coating, artwork and production requirements.
Sample availability can be confirmed according to thickness, width, lacquer and sealing requirements. Production-representative machine trials are recommended before commercial approval.
Please provide candy type, wrapping format, machine model, current and target speed, foil thickness, width, tensile or elongation requirements, CoF target, heat-seal or cold-seal requirements, roll dimensions, food-contact documentation, quantity and destination.
